APC Smart-UPS Lithium-Ion 750VA 120V Short Depth with SmartConnect Rack-Mountable (SMTL750RM2UC)
This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. The 750VA line interactive 2U short depth rackmount UPS provides pure sine wave power to support critical electronics during power disruptions. It comes with NEMA 5-15P input and 6x NEMA5-15R outlets. This rackmount UPS is tower convertible with the mounting stabilizing feet (SMTL2USF sold separately).It offers cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and proactive email notifications with recommended actions.
It has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. It provides surge protection against lightning strikes, power sags, brownouts and surges. The SMTL UPS has a 5-year warranty on the UPS and Lithium-ion battery.
Highlights:
- This model is not sold in Vermont
- 750VA / 600W Pure Sine Wave UPS battery backup
- APC SmartConnect is the first cloud-enabled UPS for Distributed IT. Through a secure portal (via any internet-connected device), you can view the status of your UPS, receive notifications, get firmware updates and more.
- Multi-Function LCD Display to view VA load/watts/amps, input/output voltage and frequency, Battery capacity and runtime and more
- Input: NEMA 5-15P. Output: (6) NEMA 5-15R. Nominal Input/Output Voltage: 120V
- FREE Additional 1 Year of Battery Warranty when you connect and register this APC UPS with SmartConnect
- 2U Rackmount UPS. Includes rack mounting support rails
SPECIFICATIONS
| MODEL NUMBER | SMTL750RM2UC | |||||
| Power rating | 750VA(500W) | |||||
| Voltage nominal | 120V | |||||
| Frequency range |
50/60 Hz
|
|||||
| Voltage |
120V
|
|||||
| Waveform | Sine wave | |||||
| Transfer time (typical) | 6ms | |||||
| Recharge Time | 3 Hrs | |||||
| Efficiency | 75...154 V adjustable 82...144 V |
|||||
| Battery type | Lithium- ion |
|||||
| Dimensions (W x D x H) | 9 x 23 x 18.6 in | |||||
| Weight | 39 lbs | |||||
| Input connection |
NEMA 5-15P
|
|||||
| Output connection |
(6) NEMA 5-15R
|
|||||
| Operating temperature |
32…104 °F (0…40 °C)
|
|||||
| Audible noise | < 41 dBA | |||||
| Altitude |
0…25000ft (0.00…7620.00 m)
|
|||||
| Warranty |
5 year warranty or replace
|
|||||
| Other |
Alarm when on battery :
distinctive low battery alarm :
configurable delays
|
|||||
