APC Smart UPS SURT6000RMLXT3U 6kVA / 4.2KW 208V Rack / Tower UPS
APC Smart UPS SURT6000RMLXT3
Professionally re-certified with new batteries installed. May not include mounting hardware or communication options and may show minor signs or ware consistent with previous installation/removal.
NOTE: Serial number of unit may be different than seen in photos due to multiple units being available.
Output:
|
Output power capacity |
4.2kW / 6.0kVA |
||||
|
Max Configurable Power (Watts) |
4.2kW / 6.0kVA |
||||
|
Nominal Output Voltage |
208V |
||||
|
Output Voltage Note |
Configurable for 208 or 240 nominal output voltage |
||||
|
Efficiency at Full Load |
92.0 % |
||||
|
Output Voltage Distortion |
Less than 3% |
||||
|
Output Frequency (sync to mains) |
50/60 Hz +/- 3 Hz user adjustable +/- 0.1 |
||||
|
Other Output Voltages |
240 |
||||
|
Load Crest Factor |
3:1 |
||||
|
Topology |
Double Conversion Online |
||||
|
Waveform type |
Sine wave |
||||
|
Output Connections |
|
||||
|
Bypass |
Internal Bypass (Automatic and Manual) |
Input:
|
Nominal Input Voltage |
208V |
||
|
Input frequency |
50/60 Hz +/- 5 Hz (auto sensing) |
||
|
Input Connections |
|
||
|
Cord Length |
10ft (3.05meters) |
||
|
Input voltage range for main operations |
160 - 280V |
||
|
Input voltage adjustable range for mains operation |
100 - 280V |
||
|
Number of Power Cords |
1 |
||
|
Efficiency at Full Load |
92.0 % |
||
|
Other Input Voltages |
240 |
Physical:
|
Maximum Height |
5.1 inches (130mm, 13.0cm) |
|
Maximum Width |
17.0 inches (432mm, 43.2cm) |
|
Maximum Depth |
26.0 inches (660mm, 66.0cm) |
|
Rack Height |
3U |
|
Net Weight |
120.0 lbs. |
