TrippLite 3000VA 2.7kW 120V Double-Conversion UPS (SU3000RTXLCD3U)
*Preowned* TrippLite 3000VA 2.7kW 120V Double-Conversion UPS (SU3000RTXLCD3U)
On-line double-conversion UPS provides pure sine wave AC output to server and network equipment in data centers and computer rooms.
Highlights:
- Offers network-grade protection against power failures and voltage fluctuations
- Zero transfer time between on-line and battery modes for uninterrupted operation
- ENERGY STAR-certified to save electricity, lower costs, and protect the environment
Specifications:
| UPC code |
037332169426 |
| UPS type |
Online |
| Rated input current (max) |
24A |
| Nominal input voltage |
120V |
| Input connection |
L5-30P |
| Input circuit breakers |
40A |
| Cord length |
10ft |
| Phase |
Single-phase |
| Output capacity |
3000VA/2700W |
| Power factor | 0.9 |
| Crest factor |
3:1 |
| Frequency |
50/60 Hz |
| Output connections | (4) 5-15R; (4) 5-15/20R; (1) L5-30R |
| Waveform |
Pure sign wave |
| Battery type |
Valve Regulated Lead Acid (VRLA) |
| Runtime Full Load (min.) | 4 min. (1350W) |
| Runtime Half Load (min.) | 11 min. (675W) |
| Expandable runtime |
yes |
| DC system voltage | 72VDC |
| Weight |
74lbs |
| Dimensions (HxWxD) |
5.25 x 17.75 x 26 in |
NOTES:
System retired from functional setting and may show signs of wear consistent with previous installation/removal.
System has been professionally tested & load banked for functionality.
NEW Batteries installed
Due to multiple units being available - serial number and data tag of unit purchased may be different than pictured
